Transair® Drop Brackets for Aluminum Pipe - RR63 V12N16-SF

Name: Transair® Drop Brackets for Aluminum Pipe - RR63 V12N16-SF
SKU: RR63 V12N16-SF

Transair® Drop Brackets are designed for the quick and easy addition of drop lines to an existing compressed air pipe or inert gas system.

Availability:

Backordered

SKU RR63 V12N16-SF

POR

Qty:

Products specifications

Attribute name	Attribute value
Body Material	Steel / Zinc-plated	Connection 2 Size	2"
Connection 2 Type	Female Threaded NPT Saddle Reducing Bracket	Connection 1 Size	8" (220 mm)
Connection 2 Type	Female	Weight	11.6 lb
Body Material	Steel	Brand	PARKER
Shape	Saddle	Connection 2 Size	2 inch
Technology	Pneumatics	Product Type	Compressed Air Piping
Assembly	Drop	Configuration	Pipe to Port
Vacuum Pressure Rating	0.03 inch-Hg 99,9% (absolute pressure)	Division	Fluid System Connectors Division
Plating Type	Zinc-plated	For Fluid Type	Air
Assembly Time	0.1 Hours	Maximum Operating Temperature	185 °F
Application	In Plant Pneumatic	Division	Fluid System Connectors Division
Specifications Met	ISO 9001	Industry	General Industrial
Minimum Operating Temperature	-4 °F	Product Style	Quick Assembly Bracket
Maximum Operating Pressure	150 psi	Silicone Free	Yes
Quantity per Box	1	Connection 1 Size	220 mm
Connection 1 Type	Pipe
