Picture of Transair® Fittings for Stainless Steel Pipe - RR02 N7 01

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Transair® Fittings for Stainless Steel Pipe - RR02 N7 01

Transair Fittings for Stainless Steel Pipe are quick and easy to install. Available in EPDM and FKM seals for maximum chemical compatibility.
Availability:
Backordered
SKU RR02 N7 01
POR
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Products specifications
Attribute nameAttribute value
Seal MaterialEPDMPipe O.D. (mm)22
Pipe O.D. 2 (inch)N/AConnection Thread Size (inch)n/a
Shape90° ElbowPipe O.D. (inch)3/4
Pipe O.D. 2 (mm)N/AMinimum Operating Temperature-4 °F
Connection 1 TypePipeProduct StyleElbow
ShapeElbow 90°Vacuum Pressure Rating1 mbar
Maximum Operating Pressure145 psiBrandTransair
Assembly Time0.04 HoursConnection 2 TypePipe
ConfigurationPipe to PipeApplicationProcess Water
Weight0.36 lbProduct TypeElbow
DivisionFluid System Connectors DivisionConnection 2 Size22 mm
Quantity per Box5.0DivisionFluid System Connectors Division
Maximum Operating Temperature194 °FPipe Outside Diameter3/4 inch
Connection 1 Size3/4 inchSeal MaterialEPDM
