Transair® Valves for Aluminum Pipe - VR02 L3 00

Name: Transair® Valves for Aluminum Pipe - VR02 L3 00
SKU: VR02 L3 00

Transair® Valves are designed for quick and easy integration into a Transair compressed air piping system. Placing valves at strategic points allows for easy system isolation.

Availability:

Backordered

SKU VR02 L3 00

POR

Qty:

Products specifications

Attribute name	Attribute value
Connection Thread Size (inch)	n/a	Vented	No
Silicone Free	Yes	Pipe O.D. (mm)	101
Pipe O.D. (inch)	4	Style	Butterfly Valve
Brand	Transair	Division	Low Pressure Connectors Europe Division
Division	Fluid System Connectors Division	Assembly Time	0.15 Hours
Minimum Operating Temperature	-20 °C	Industry	General Industrial
Technology	Fluid & Gas Handling	Application	In Plant Pneumatic
Mounting Type	Flanged	Seal Material	NBR
Specifications Met	EN 755.2	Vacuum Pressure Rating	0.03 inch-Hg
Maximum Operating Pressure	232 psi	Maximum Operating Temperature	185 °F
Quantity per Box	1	For Fluid Type	Inert Gases
Function	2-Way	Body Material	Cast Iron
Product Type	Flow Control Valve	Flow Direction	Bidirectional
Actuation Type	Manual	Options	Lockable
Response Time	n/a	Operation Type	Manual
Product Style	Butterfly Valve	Configuration	Pipe to Flange
Connection 1 Size	4 inch	Connection 2 Size	100 mm
Connection 2 Type	Flange	Orifice Size	4 inch
Seat Material	NBR	Weight	4.300 kg
Connection 1 Type	Flange
