Picture of Transair® Valves for Aluminum Pipe - VVP502P-8*

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Transair® Valves for Aluminum Pipe - VVP502P-8*

Transair® Valves are designed for quick and easy integration into a Transair compressed air piping system. Placing valves at strategic points allows for easy system isolation.
Availability:
Backordered
SKU VVP502P-8*
POR
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Products specifications
Attribute nameAttribute value
Pipe O.D. (mm)N/ASilicone FreeYes
VentedNoPipe O.D. (inch)N/A
StyleDouble Female NPT Threaded Ball ValveConnection Thread Size (inch)1/2
Product TypeFlow Control ValveSeat MaterialPTFE
Body MaterialBrassIndustryGeneral Industrial
Minimum Operating Temperature0Vacuum Pressure Rating1
Connection 2 Size1/2Specifications MetN/A
Maximum Operating Pressure17.2Maximum Operating Temperature350
Weight0.700Connection 2 TypeFemale NPT
Mounting TypeScrewFlow DirectionBidirectional
OptionsLockableConfigurationPort to Port
Function2-WayConnection 1 Size1/2
Quantity per Box8BrandTransair
Orifice Size16.5Operation TypeManual
TechnologyFluid & Gas HandlingApplicationIn Plant Pneumatic
DivisionLow Pressure Connectors Europe DivisionSeal MaterialPTFE
DivisionFluid System Connectors DivisionFor Fluid TypeCompressed Air
Actuation TypeManualConnection 1 TypeFemale NPT
Product StyleBall ValveAssembly Time0.17
Response Timen/a
