Transair® Wall Brackets for Aluminum Pipe - 6637 25 21

Name: Transair® Wall Brackets for Aluminum Pipe - 6637 25 21
SKU: 6637 25 21

Transair® Wall Brackets are designed for quick connection of machinery or tools to compressed air piping systems or inert gas supply lines.

Availability:

Backordered

SKU 6637 25 21

POR

Qty:

Products specifications

Attribute name	Attribute value
Pipe O.D. (mm)	25	Pipe O.D. (inch)	1
Connection Thread Size (inch)	n/a	Shape	3 port Wall Bracket with Ball Valve
Brand	PARKER	Division	Low Pressure Connectors Europe Division
Assembly Time	0.15 Hours	Minimum Operating Temperature	-4 °F
Shape	Straight	Division	Low Pressure Connectors Europe Division
Assembly	n/a	Industry	General Industrial
Technology	Fluid & Gas Handling	Seal Material	NBR
Application	Inert Gases	Specifications Met	ASME B31.1 - 31.9
Maximum Operating Temperature	185 °F	For Fluid Type	Air
Connection 1 Type	Pipe	Connection 2 Type	Female BSPP
Body Material	Technical Polymer	Quantity per Box	2
Configuration	Pipe to Port	Connection 1 Size	25 mm
Weight	3,816 lb	Product Type	Wall Brackets
Connection 2 Size	G 1/2 inch	Maximum Operating Pressure	232 psi 232 PSI (-4°F to +113°F)/16 bar (-20°C to 45°C) up to 100 mm 188 PSI (-4° to +140°F)/13 bar (-20°C to 60°C) up to 168 mm 101 PSI (-4° to +185°F)/7 bar ( -20°C to 85°C) up to 168 mm For Canada, Please refer to https://www.parker.com/c
Connection 3 Size	G 1/4 inch	Connection 3 Type	Female BSPP
