Transair® Wall Brackets for Aluminum Pipe - 6678 17 21

Name: Transair® Wall Brackets for Aluminum Pipe - 6678 17 21
SKU: 6678 17 21

Transair® Wall Brackets are designed for quick connection of machinery or tools to compressed air piping systems or inert gas supply lines.

Availability:

Backordered

SKU 6678 17 21

POR

Qty:

Products specifications

Attribute name	Attribute value
Pipe O.D. (mm)	16.5	Pipe O.D. (inch)	1/2
Connection Thread Size (inch)	n/a	Shape	1 Port 45° Wall Bracket with Ball Valve
Brand	Transair	Division	Low Pressure Connectors Europe Division
Assembly Time	0.15 Hours	Minimum Operating Temperature	-20 °C
Shape	Straight	Division	Low Pressure Connectors Europe Division
Maximum Operating Temperature	85 °C	Assembly	n/a
Industry	General Industrial	Seal Material	NBR
Application	Compressed Air	Specifications Met	ISO 8573 (Air Quality)
Technology	Pneumatics	For Fluid Type	Industrial Gas
Connection 1 Type	Pipe	Maximum Operating Pressure	16 bar
Connection 2 Type	Female BSPP	Body Material	Treated Brass
Quantity per Box	2	Connection 1 Size	1/2 inch
Configuration	Pipe to Port	Weight	0,872 kg
Product Type	Wall Brackets	Connection 2 Size	G 1/2 inch
Connection 3 Size	G 1/4 inch	Connection 3 Type	Female BSPP
