Transair® Wall Brackets for Aluminum Pipe - 6693 17 21

Name: Transair® Wall Brackets for Aluminum Pipe - 6693 17 21
SKU: 6693 17 21

Transair® Wall Brackets are designed for quick connection of machinery or tools to compressed air piping systems or inert gas supply lines.

Availability:

Backordered

SKU 6693 17 21

POR

Qty:

Products specifications

Attribute name	Attribute value
Pipe O.D. (mm)	16.5	Pipe O.D. (inch)	1/2
Connection Thread Size (inch)	n/a	Shape	2 Port 45° Wall Bracket with Ball Valve
Brand	Transair	Division	Low Pressure Connectors Europe Division
Division	Fluid System Connectors Division	Assembly Time	0.15 Hours
Minimum Operating Temperature	-4 °F	Shape	Straight
Assembly	n/a	Industry	General Industrial
Seal Material	NBR	Application	Industrial Gas
Specifications Met	EN 573.3	Maximum Operating Temperature	185 °F
Technology	Pneumatics	For Fluid Type	Air
Connection 1 Type	Pipe	Connection 2 Type	Female BSPP
Body Material	Treated Brass	Quantity per Box	2
Connection 1 Size	1/2 inch	Configuration	Pipe to Port
Product Type	Wall Brackets	Connection 2 Size	G 1/2 inch
Maximum Operating Pressure	232 psi 232 PSI (-4°F to +113°F)/16 bar (-20°C to 45°C) up to 100 mm 188 PSI (-4° to +140°F)/13 bar (-20°C to 60°C) up to 168 mm 101 PSI (-4° to +185°F)/7 bar ( -20°C to 85°C) up to 168 mm For Canada, Please refer to https://www.parker.com/c	Connection 3 Size	G 1/4 inch
Connection 3 Type	Female BSPP	Weight	2,535 lb
